UVP GelStudio Series

  • Imager for gel documentation in two different sizes
  • Available as a touch screen controlled or as an external computer operated system
  • High sensitivity camera and optics

Product Details

  • Integrated multi-touch computer, with large storage capacity, ideal for multitasking and viewing several images
  • Wide maximum illuminated imaging area for imaging multiple gels of various sizes (up to 25 x 26 cm)
  • Available with a unique "Slide2Hide" door which features smooth operation and limits bench top interferences
  • Integrated UV Protection Shield, maximizes protection from UV radiation while working over the transilluminated surface
  • Overhead white, red, green and blue LEDs included
  • Five-position automated filter tray for easy access (Ethidium bromide filter included)
  • Upgradeable to support UVP eLITE Light Source module, for excitation from 400 to 800 nm wavelength applications
  • VisionWorks Software, with comprehensive features, optimizes image acquisition and analysis
  • Fully networkable system that can connect over wireless network for simple transfer of files and data

UVP GelStudio imagers offer high-resolution and sensitive imaging of DNA & protein gels. They also work with an unlimited range of excitable stains and dyes. All imagers run the powerful VisionWorks Software, full package image capture, enhancement functions and analysis software. Application-based icons for automation, which are included in the software package, offer one-touch capture. The software allows for creating custom icons and workflows based on users’ needs. The UVP GelStudio guarantees top image quality and an optimized range of high performance features. With its high resolution camera, high dynamics and excitation ranges from 400 to 800 nm, this series introduces a new benchmark that goes far beyond publication-quality images.

Applications

Pharma & Life Science

Show applications

Applications

Technical Data

Specifications/
features
UVP GelStudioUVP GelStudio PLUS
Light sources
  • Overhead: white, red, green and blue LEDs included
  • Base lighting: Thin-Line Transilluminator, (302 nm) with High/Low intensity control
  • Illuminated area: 16.8 x 21 cm


  • Overhead white, red, green and blue LEDs included
  • Base lighting: Thin-Line Transilluminator, (302 nm) with High/Low intensity control
  • Illuminated area: 25 x 26 cm

Filter wheelFive-position automated filter wheel
Darkroom features
  • 13.3” integrated, multi-touch computer
    (UVP GelStudio touch only)
  • Fold-down door
  • Thin-Line Transilluminator in a pull-out tray
  • UV On indicator light
  • USB port (right side of unit)
  • 6 additional USB ports (back side of unit)
  • Access port for optional UVP eLITE Light Source


  • 15.6” integrated, multi-touch computer
    (UVP GelStudio PLUS touch only)
  • Slide2Hide door
  • Thin-Line Transilluminator in a pull-out tray
  • UV On indicator light
  • USB port (right side of unit)
  • 6 additional USB ports (back side of unit)
  • Access port for optional UVP eLITE Light Source

Accessories included
  • Ethidium bromide filter
  • VisionWorks Software for image capture,
    enhancement and analysis (unlimited licenses)
  • Flash drive with VisionWorks Software (license free)
  • UVP Fluorescent Focus Target
  • UV Gel Tray
  • UV Protection Shield
  • Empty flash drive for data and image storage
  • Keyboard and mouse (touch screen systems only)


  • Ethidium bromide filter
  • VisionWorks Software for image capture,
    enhancement and analysis (unlimited licenses)
  • Flash drive with VisionWorks Software (license free)
  • UVP Fluorescent Focus Target
  • UV Gel Tray
  • Integrated UV Protection Shield
  • Empty flash drive for data and image storage
  • Keyboard and mouse (touch screen systems only)

Dimensions:
L x W x H
41 x 46 x 61 cm (16 x 18 x 24 inch)43 x 47 x 82 cm (17 x 19 x 32 inch)
Wireless network
capability
Wireless network capable, Wi-Fi, accessory for
wired-to-ethernet connection available
Wireless network capable, Wi-Fi, accessory for
wired-to-ethernet connection available

Order Information

Order numberDescription
115 V230 VName

849-97-0852-01

849-97-0852-02UVP GelStudio touch
849-97-0852-03849-97-0852-04UVP GelStudio
849-00553-4849-00553-2

UVP GelStudio PLUS touch

849-00552-4849-00552-2UVP GelStudio PLUS
MultiSpectral Light Sources
Order numberDescription
115 V230 VName

98-0105-01

98-0105-02UVP eLITE Xenon, kit with Epi-Light fibers
98-0072-0798-0072-07UVP eLITE motorized, kit with Epi-Light fibers
Order numberDescription
Transilluminators
95-0476-01UVP Visi-White™ LED Transilluminator, 28 cm x 28 cm
95-0591-01UVP Visi-Blue™ LED Transilluminator, 24.5 cm x 24.5 cm
95-0599-01UVP Visi-White™ LED Transilluminator, 16.8 cm x 21 cm
95-0593-01UVP Visi-Blue™ LED Transilluminator, 16.8 cm x 21 cm
Converter Plates
38-0428-01UVP Visi-White™ Converter Plate UV-to-white, 25 cm x 26 cm filter size
38-0200-04UVP Visi-Blue™ Converter Plate, 25 cm x 26 cm filter size, 460-470 nm
38-0408-01UVP Visi-White™ Converter Plate UV-to-white, 16.8 cm x 21 cm filter size
38-0409-01UVP Visi-Blue™ Converter Plate, 16.8 cm x 21 cm filter size, 460-470 nm
Emission Filters
38-0220-01Emission filter 580 - 630 nm: EtBr
38-0219-01Emission filter 510 - 560 nm: SYBR® Green
38-0221-01Emission filter 520 - 620 nm: SYBR® Gold
38-0361-01Emission Filter 465 - 495 nm: CFP mice
38-0352-01Emission Filter 503 - 523 nm: GFP mice
38-0340-01Emission Filter 513 - 557 nm: Cy2®, FITC, FAM™, GFP, SYBR® Green, SYBR® Gold
38-0344-01Emission Filter 565 - 625 nm: Alexa555®, Cy3®, SYPRO® Orange
38-0341-01Emission Filter 607 - 682 nm: Alexa568®, SYPRO® Red, TexasRed®
38-0339-01Emission Filter 668 - 722 nm: Alexa633®, Cy5®
38-0369-01Emission Filter 700 - 740 nm: IRDye 680, CF 680
38-0362-01Emission Filter 767 - 807 nm: Alexa750®, Cy7®
38-0365-01Emission filter 780 nm long pass: Alexa750®
38-0368-01Emission filter 800 nm long pass: IRDye800, CE770
Additional Accessories
89-0069-06UVP Thermal printer Mitsubishi P95DE, high resolution (325 dpi), USB 2.0 interface, 100 - 240 V, dimensions 8.5 x 15.4 x 23.9 (H x W x D cm)
89-0174-01Thermal printer paper K95HG, high glossy, 5 rolls at 18 m
89-0038-01Thermal printer paper KP65HM, high contrast, 4 rolls at 20 m
85-0007-01UV transparent acrylic tray for preparative tasks on a transilluminator, 11.5 in x 9 in
85-0003-01UVP Gel-Ruler
85-0002-01UVP Gel-Cutter
85-0006-01UV transparent gel scoop, scoop size 14 cm x 15 cm
98-0064-01Focus target, fluorescent
98-0002-04UV light face protection shield

Downloads

Product Brochure UVP GelStudio Imaging Systems
